PIPE INDUCTION HEATING EQUIPMENT

Parmaprogetti Logo.gif

Our company is a distributor for the  Italian Parmaprogetti company which a leader in pipe induction heating technologies. Parmaprogetti's has a wide range of induction heating generators for pipe preheating, field joint coating and heat treatment applications. Please use the following link for the Parmaprogetti Catalog:

Parmaprogetti Catalog


Delta 50

This inverter generator embodies the best of our 40-year experience in the induction heating field for pipelines.
This very same expertise has since been applied to all of Parmaprogetti’s generator series.
Delta50 is the smallest generator available on the market in terms of size and power supplied. Power can be adjusted to a maximum of 70 kW depending on the customer’s need.
Delta50 is the only generator that can operate connected in clusters, thereby multiplying the power available. Easy to use with simple push start and stop buttons, it has different levels of programming, which make it suitable for all pipeline applications.

Supplied by three-phase voltage, this generator operates exclusively with power-factor 1, even during the heating phase, thus preventing magnetic loss in the output cables and allowing for runs of more than 100 m to be set up.

Thanks to its unique characteristics, Delta50 is unrivaled in offshore applications, where it is often used together with a twin generator, which is always available in the event that a dual power supply is required or a ready-to-use spare generator is needed for maintenance purposes.

Delta50 is effective when employed in onshore applications too, as it is easy to transport and can be supplied by a small genset or with other set-ups.


Delta 200

The Delta200 inverter generator combines high power and small dimensions and is very easy to use thanks to Parmaprogetti’s exclusive software for induction heating. Power can be adjusted from the maximum to the minimum value depending on the three-phase power supply available.

Just as high-performing as all of our induction heating generators, Delta200 is mostly used when the period of time required for heating is very short or when a metal mass needs to be heated to a very high temperature. This makes it the best solution for coating plants, as it does not cause dephasing or interfere with the mains power supply and no additional cooling circuits are needed.


Delta 350

The Delta350 inverter generator combines high power and small dimensions and is very easy to use thanks to Parmaprogetti’s exclusive software for induction heating. Power can be adjusted from the maximum to the minimum value depending on the three-phase power supply available.

Just as high-performing as all of our induction heating generators, Delta350 is mostly used when the period of time required for heating is very short or when a metal mass needs to be heated to a very high temperature. This makes it the best solution for a coating plant, as it does not cause dephasing or interfere with the mains power supply and no additional cooling circuits are needed.


Giano 200

Giano200 is the only self-supplied generator on the market with the dual function of supplying both single-phase voltage with variable frequency for induction heating and, at the same time, three-phase voltage for powering welding machines and other accessories.

Thanks to the built-in inverter and to the same advanced technology used in all Parmaprogetti’s static generators, Giano200 is able to transfer up to 200 kW during the pipe-heating process. The power produced is enough to achieve the best performance levels in all preheating and coating applications in the onshore sector.

Parmaprogetti guarantees full customer support. Spare parts and set-ups can be provided on request.

IH TRACTOR.PNG

Mach 2 ve Mach 3 Induction Heating Tractors


Heating coils for various applications
